2. Central control unit

Programmable central control is used and 55 sizes can be set on the same shaft for auto cutting.

3. Operating panel

All functions are operated on the 10"LCD touch panel.

4. Motor control system

The central control system is PLC programmable controller.

5. Cutting positioning system:

Cutting positioning is controlled by Mitsubishi servo motor. The imported high precision ball screw is applied to set the size and the linear slide rail is to bear the load of the cutter seat.

6. Blade feeding positioning system

Blade feeding is controlled by Mitsubishi servo motor, and the cutting speed is adjustable in three stages.

7. Auto angle adjustment of circular blade

Mitsubishi servo motor is used to calculate the circular blade angle and the angle change is subject to different materials (the angle change range is ±8°).

8. Auto exchange device

Cam divider system for fast and accurate exchange, no stuck issue.

9. Quick shaft change system:

Three kinds of shafts are available and quick change of shafts is applied for different materials.

2. Cutting supporter

For supporting log roll when cutting core below 38mm.

Max. Cutting O.D.

150mm

Inner core I.D.

1"-3"

Min. Cutting width

3mm
